Quick Details:
Product Description:
220V 4 Clamps Pipe Fusion Butt Fusion Welding Machine
Manually Operated HDPE butt fusion welding machine is suitable for PE and PP pipes and fittings. High quality design and construction provides an excellent machine for welding both on the worksite and in the factory. The use of high quality Aluminum casting allows for lower weight without compromising strength and performance.
Specifications:
Model No. | 2.48-7.87”(63-200MM)four rings manual |
Materials | Aluminum alloy casting, 45# steel |
Welding level(Φ, mm)outer dia | 63mm(2.48”),75mm(2.48”),90 mm (3.54”),110 mm (4.33”),125 mm (4.92”),140 mm (5.51”),160 mm (6.30”),180 mm (7.09”),200mm(7.87”) |
Docking deviation | ≤0.3mm |
Power of Heater | 1.5KW/220V |
Power of Milling Cutter | 0.85KW/220V |
Working temperature | 300°c |
Temperature deviation | ±5°c |
Environment temperature | -5……40°c |
Time required to reach soldering temperature | <20min |
Materials can be welded | PE PP PB PVDF HDPE PVC |
Weight | 105LB(48kg) |
Package Size | 24*17*17"(61*44*43cm) |
Payment:
1) Payment is expected to be received within 3 days of auctions close.
2) AliExpress supports Visa, MasterCard, Maestro Debit Card,Western Union, Bank Transfer, through secure payment processor ESCROW.
3) Please be assured your payment is safety kept by AliExpress until you confirm the delivery of your order.
Shipment:
1) We ship orders to most countries by kinds of shipping methods(based on your delivery address) ,16-40 working days for delivery time.Brazil and Russia may reach over 35-60 days.
2) Item are shipped within 7 business days once full payment is settled.
3) If you can't get your items in time,please contact to us first,we wil check and solve it for you soon.
4) We will reply your mail within 24 hours normally. sometimes have a little delay due to the weekend or holidays.
5)If you can't get our mail after 48 hours,please check your spam or contact to us with other mail address.
Return Warranty
1)If your purchase do not meet merchantable quality, fitness for purpose or match the description, We can make sure your issues are resolved .
2)For wrongly-shipped items, Please contact us in 48 hours after delivery.We will arrange to deliver the correct items or return all your payment.
Rating&Feedback
We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important for us ! We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns.
Product Features:
220V Pipe Fusion Welder Tool 63-200mm Suitable for butt welding of plastic pipes and fittings made of HDPE, PPR and PVDF in a ditch in worksite or workshop.
※ Consists of basic frame, hydraulic unit, planing tool, heating plate, support for planing tool & heating plate, and optional parts.
※ Removable PTFE coated heating plate with high accurate temperature control system;
※ Electrical planing tool.
※ Be made of lightweight and high strength material; simple structure, small and delicate, user friendly.
※ Low starting pressure ensures reliable welding quality of small pipes.
※ Changeable welding position enables to weld various fittings more easily.
※ High accurate and shockproof pressure meter indicates clearer readings.
※ Separate two-channel timer records time in soaking and cooling phases.
