HDPE PE Pipe PN 1.25 Mpa

    Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers

    Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers
    • Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers
    • Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers
    • Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers
    • Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers
    • Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers
    • Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers
    • Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers
    • Buy cheap HDPE PE Pipe PN 1.25 Mpa from wholesalers

    HDPE PE Pipe PN 1.25 Mpa

    Ask Lasest Price
    Brand Name : SENPU
    Certification : WRAS, ISO, CE, IAPMO R&T
    Model Number : DN16MM-DN1500MM
    Price : 2.75USD/METER
    Delivery Time : 5-10 working days
    Payment Terms : TT, L/C
    • Product Details
    • Company Profile

    HDPE PE Pipe PN 1.25 Mpa


    Pipe Description


    Product Name

    PE100 Water Supply HDPE Pipe

    Material

    High-Density Ppolyethylene

    Standard

    GB/T13663-2000,ISO 4427-1:2007

    Specification

    dn20-dn1200

    Pressure

    SDR11,13.6,17,21,26

    Length

    6 meters or as needed, dn20-dn63 can produce coils

    Main application

    Water Supplying and Draining


    Product Specification








    Pressure

    OD

    (mm)

    PN0.6MPa SDR 26

    Thickness

    (mm)

    PN0.8MPa SDR 21

    Thickness (mm)

    PN1.0MPa SDR 17

    Thickness (mm)

    PN1.25MPa SDR 13.6

    Thickness (mm)

    PN1.6MPa SDR 11

    Thickness (mm)

    63



    3.7

    4.7

    5.8

    75



    4.5

    5.6

    6.8

    90


    4.3

    5.4

    6.7

    8.2

    110

    4.2

    5.3

    6.6

    8.1

    10.0

    125

    4.8

    6.0

    7.4

    9.2

    11.4

    140

    5.4

    6.7

    8.3

    10.3

    12.7

    160

    6.2

    7.7

    9.5

    11.8

    14.6

    180

    6.9

    8.6

    10.7

    13.3

    16.4

    200

    7.7

    9.6

    11.9

    14.7

    18.2

    225

    8.6

    10.8

    13.4

    16.6

    20.5

    250

    9.6

    11.9

    14.8

    18.4

    22.7

    280

    10.7

    13.4

    16.6

    20.6

    25.4

    315

    12.1

    15.0

    18.7

    23.2

    28.6

    355

    13.6

    16.9

    21.1

    26.1

    32.2

    400

    15.3

    19.1

    23.7

    29.4

    36.3

    450

    17.2

    21.5

    26.7

    33.1

    40.9

    500

    19.1

    23.9

    29.7

    36.8

    45.4

    560

    21.4

    26.7

    33.2

    41.2

    50.8

    630

    24.1

    30.0

    37.4

    46.3

    57.2

    710

    27.2

    33.9

    42.1

    52.2


    800

    30.6

    38.1

    47.4

    58.8


    900

    34.4

    42.9

    53.3



    1000

    38.2

    47.7

    59.3



    1200

    45.9

    57.2





    HDPE pipe water and gas difference


    The application scope of HDPE pipe is very wide. According to the field of use, it can be divided into water field, gas field, mining field, etc.The difference between water supply pipe and gas pipe is not very big in appearance, but there are still subtle differences.

    1-1P1300T525347

    1. Execution standard -- THE national standard of PE water pipe is GB/T13663-2000; The national standard of PE gas pipe is GB 15558.1-2003 (old standard) and GB 15558.1-2015.

    2. Raw materials - PE pipe raw material is high density polyethylene, white granular master material and 2%-3% of the black master mixed; PE gas pipe used as the raw material for gas pipe special material, belongs to the mix ingredients, the color is black.

    3. Appearance color - PE pipe wall color is generally black with four blue lines, some also made of white pipe body or other colors with blue lines; PE gas pipe is usually black pipe body with yellow line or orange line.

    4. Specification - PE water supply pipe general specification for DN16mm - DN1400mm; The general specification of PE gas pipe is DN20mm-DN630mm, but the general specification is below DN315mm, and the specification above 315mm is usually cast iron pipe.

    .

    Product Details


    202111151456130d6abb9626894691a99b4fcf434eaf3f

    202111151456141e9753fb84544f2291f0f4c73fa797ef

    20211115145614ac702b54f9124cdc8023849df0d4d7cd


    Product Pictures




    202111151507017fb345fcb09b4769aa70c223ccb19f95

    20211115150702f0e4e068a7944637997319ffe2cc2266

    202111151507035a05e2a4a26e4002b512d0ea16fb89aa

    20211115150707f7695eb590084a9f84525f6c8916fcf8

    2021111515070732bc99b4d38745d58bf9b4719f075da8

    Quality Assurance


    1.Professional

    All processing stages have an automated management system. Metal cutting, molding, assembly and testing.

    2.Stock

    We can delivery the goods fast, also provide the samples.

    3.Service

    24 hours service, welcome to calling to us by

    After Sales: We do take full responsibility for our SENPU Branded products. Should you encounter any difficulties with our products feel free to contact us immediately. We will assist you to the best of our knowledge.


    Warehouse Display


    20210805165411a55a4fe359cc4d998b1b4aa36ff9b87b

    20210802153640a641eea04a8e46499f56b2b2dcd48349

    202108021536428dc66aa661ab43d982560f89a835a7e9

    202108021536423ca1b323f15747138b3d2a4ca2ba0c3a

    202108021536431be61b4de4fe49a18f3df6b0869ab90a

    20210802153645d0216d8346a14984b0d4ced8d70194a1

    20210802153645983b044523e44bb5aa4bf1c84e0f6fdc
